Addressable Manual Call Point
Model No. FMS-CP1-R
General
The addressable manual call point connects to the addressable fire alarm control panel. Up to 256 devices can be connected to each loop of the FMS-R fire alarm control panel. The devices has an integral alarm indicator that illuminate when the manual call point has been pushed down.
Features
- DCP protocol for fast and robust communication
- Use standard cable, no shielded or twisted pair required on SLC loop
- Up to 256 devices can be used on per loop
- LED indicator can show normal, alarm and failure status
- With emergence telephone jack
- Address is easily to set by DIP switch
Thông số kỹ thuật
| Operating Voltage | DC18V ~ 30V |
| Quiescent Current | ≤ 0.5mA |
| Dòng báo động | 18mA (max) @ DC 24V |
| Alarm Temperature | Rise up to 30℃ during 30 seconds |
| LED indications | Normal：flash one time per 6 sec.
Alarm：always on Failure：flash 2 times per 6 sec. |
| Operating Temperature | -10℃ ~ 50℃ |
| Relative Humidity | <95% RH, non-condensing |
| Material / Color | Fire-proof plastics / Red |
| Kích thước | Φ140*50mm |
